Water Process &
Desalination Valves
Coral Valves cover a full range of automated and manually operated Isolation and Control valves for all process sectors, Including Water Treatment Plants, Desalination plants, Steel Mills, Sugar Mills, Food & Beverage and various steam applications.
Valve & Actuator Range
Butterfly Valves
-
Size Range: DN40 - DN1200
Pressure: PN10 - PN16
Configuration: Rubber Lined (Replaceable) / PTFE
Construction: Concentric / Double Eccentric
Materials: Cast Iron / Ductile Iron / Carbon Steel / Stainless Steel
Gate Valves
-
Size Range: 1/4" - 48"
Pressure: Class 150 - Class 2500
Construction: Bolted Bonnet / Pressure Seal
Materials: Cast Iron / Carbon Steel / Stainless Steel Alloys
Globe Valves
-
Size Range: 1/4" - 48"
Pressure: Class 150 - Class 2500
Construction: Bolted Bonnet / Pressure Seal
Materials: Cast Iron / Carbon Steel / Stainless Steel Alloys
Check Valves
-
Size Range: 1/4" - 48"
Pressure: Class 150 - Class 2500
Construction: Bolted Bonnet / Pressure Seal
Materials: Cast Iron / Carbon Steel / Stainless Steel Alloys
Knife Gate Valves
-
Size Range: DN40 - DN1200
Pressure: PN10 - PN16
Configuration: Rubber Liner / Metal Seated
Construction: Wafer / Lugged / Flanged
Materials: Cast Iron / Carbon Steel / Stainless Steel
Desalination Plug Valves
-
Size Range: 2" - 24"
Pressure: Class 150 - Class 600
Configuration: Full Bore / Reduced Bore
End Connections: Flanged / Buttweld
Materials: Carbon Steel / Duplex / Super Duplex / Aluminium Bronze / Stainless Steel Alloys
Globe Control Valves
-
Size Range: 1/2" - 12" - Larger sizes available on request
Pressure: PN16-PN40 / ANSI Class 150 Class 300
Pneumatic Control Valves for Liquids, Gases and Steam
Materials: Carbon Steel / Low Carbon Steel / Stainless Steel Alloys
Safety Valves
-
Size Range: 1/2" x 2" - 12" x 16"
Pressure: Class 150 - Class 2500
Design to ASME VIII / API STD 526 / ISO 4126
Configuration: Conventional / Bellows Sealed
Construction: Full Lift / Semi Lift
Materials: Carbon Steel / Low Carbon Steel / Stainless Steel Alloys
Pneumatic Actuators
-
Rack & Pinion / Scotch Yoke Design
Torque: 3 N.M - 700,000 N.M
Configuration: Double Acting / Spring Return
Construction: Hard Anodized Aluminium Body & Carbon+ ENP Pinion
Coatings: Standard Anodized or C5M for harsh environments
Electric Actuators
-
Torque: 40 N.M - 3000 N.M
Configuration: Quarter Turn / Multi Turn
Construction: Hard Anodized Aluminium Body
Power Supply: 1Ph / 3Ph
Complete with Manual Override
Smart Valve Positioners
-
Smart & Analogue Type
Linear / Rotary Valve Positioners
HART / PROFIBUS / FIELDBUS Capable on order
Construction: Standard / ATEX Rater Aluminium Housing
Automation Accessories
-
Mechanical & Proximity Switchboxes, Brackets & Couplings, Bespoke Pipework, Lock up Valves, Solenoid Valves and Air Filter Regulators.
The Coral Valves Commitment.
-
Supplying Uncompromising Quality to Industries that Matter.
Coral Valves is deeply committed to providing the process, desalination, and waterworks industries with top-tier manually operated and automated isolation and control valves. Our dedication to quality is unwavering. We understand that these industries rely on precision and reliability, and that's why every valve in our range is crafted with meticulous attention to detail and rigorously tested. Our valves not only meet but exceed industry standards, ensuring optimal performance, safety, and longevity for our clients in these crucial sectors.
-
Seamless Solutions, Unmatched Support.
Our commitment extends beyond supplying valves; it encompasses steadfast support throughout your journey. Whether you're seeking manually operated or automated valves, our team of experts is ready to assist you in selecting the perfect solutions for your specific needs. From valve selection to seamless integration, we're dedicated to making the process efficient and hassle-free. Our comprehensive after-sales support ensures that your valves continue to operate flawlessly, contributing to the efficiency and dependability of your processes.
-
Partnering for Reliability and Efficiency.
At Coral Valves, we're not just about valves; we're about building enduring partnerships. Our range of isolation and control valves represents more than just hardware; it symbolizes our commitment to crafting solutions that perfectly align with the unique requirements of the process, desalination, and waterworks industries. We collaborate closely with our clients to ensure that our valves not only meet but also enhance the precision and safety of their operations. With Coral Valves as your partner, you can rely on the reliability and efficiency of your processes to flourish.
