Durable Mining Valves for Challenging Environments
We manufacture and distribute a wide range of Butterfly, Gate, Globe, Check, Plug and Control Valves for the Mining Industry.
We cover all areas of the plant, from dilution waters, mine dewatering and a variety of valves for specialty applications such as flotation tanks and cyclones.
Valve & Actuator Range
Butterfly Valves
-
Size Range: DN40 - DN1200
Pressure: PN10 - PN16
Configuration: Rubber Lined (Replaceable) / PTFE
Construction: Concentric / Double Eccentric
Materials: Cast Iron / Ductile Iron / Carbon Steel / Stainless Steel
Gate Valves
-
Size Range: 1/4" - 48"
Pressure: Class 150 - Class 2500
Construction: Bolted Bonnet / Pressure Seal
Materials: Cast Iron / Carbon Steel / Stainless Steel Alloys
Globe Valves
-
Size Range: 1/4" - 48"
Pressure: Class 150 - Class 2500
Construction: Bolted Bonnet / Pressure Seal
Materials: Cast Iron / Carbon Steel / Stainless Steel Alloys
Check Valves
-
Size Range: 1/4" - 48"
Pressure: Class 150 - Class 2500
Construction: Bolted Bonnet / Pressure Seal
Materials: Cast Iron / Carbon Steel / Stainless Steel Alloys
Knife Gate Valves
-
Size Range: DN40 - DN1200
Pressure: PN10 - PN16
Configuration: Rubber Liner / Metal Seated
Construction: Wafer / Lugged / Flanged
Materials: Cast Iron / Carbon Steel / Stainless Steel
Plug Valves
-
Size Range: 2" - 24"
Pressure: Class 150 - Class 600
Configuration: Full Bore / Reduced Bore
End Connections: Flanged / Buttweld
Materials: Carbon Steel / Duplex / Super Duplex / Aluminium Bronze / Stainless Steel Alloys
Globe Control Valves
-
Size Range: 1/2" - 12" - Larger sizes available on request
Pressure: PN16-PN40 / ANSI Class 150 Class 300
Pneumatic Control Valves for Liquids, Gases and Steam
Materials: Carbon Steel / Low Carbon Steel / Stainless Steel Alloys
Slurry Control Valves
-
Size Range: 2" - 60"
Pressure: Class 150 - Class 600
Sintered tungesten carbide trim for high velocity abrasive slurry flow control severe service mining applications
Field Replaceable Trim Kits
Pneumatic Actuators
-
Rack & Pinion / Scotch Yoke Design
Torque: 3 N.M - 700,000 N.M
Configuration: Double Acting / Spring Return
Construction: Hard Anodized Aluminium Body & Carbon+ ENP Pinion
Coatings: Standard Anodized or C5M for harsh environments
Electric Actuators
-
Torque: 40 N.M - 3000 N.M
Configuration: Quarter Turn / Multi Turn
Construction: Hard Anodized Aluminium Body
Power Supply: 1Ph / 3Ph
Complete with Manual Override
Smart Valve Positioners
-
Smart & Analogue Type
Linear / Rotary Valve Positioners
HART / PROFIBUS / FIELDBUS Capable on order
Construction: Standard / ATEX Rater Aluminium Housing
Automation Accessories
-
Mechanical & Proximity Switchboxes, Brackets & Couplings, Bespoke Pipework, Lock up Valves, Solenoid Valves and Air Filter Regulators.
The Coral Valves Commitment.
-
Engineering Excellence for Mining Challenges.
At Coral Valves, we stand by our commitment to providing top-notch solutions tailored to the unique demands of the mining industry. Our extensive mining valve range is a testament to this dedication. We ensure each valve can handle the rigors of the harshest of mining environments. At Coral Valves, we know our valves will play a vital role in maintaining the safety and efficiency of your mining operations.
-
Reliability in Harsh Conditions.
Coral Valves recognizes the diverse challenges posed by mining activities, both on the surface and underground. Our valves are constructed using durable materials, guaranteeing resistance against corrosive elements, abrasive substances, and extreme temperatures. This emphasis on resilience reflects our dedication to delivering reliable solutions that endure even in the most demanding mining environments.
-
Partners in Mining Progress.
Coral Valves is more than just a valve supplier; we are your partners in elevating the mining industry. Our solutions extend beyond quality products – they signify our drive to enhance operational efficiency, minimize downtime, and promote safer mining practices. With our comprehensive range of valves, we are honored to contribute to the industry's growth by offering solutions that align seamlessly with evolving mining needs
