Power Generation Valves

Coral Valves have a range of valves for Steam Power generation Plants From High Pressure and temperature Steam Valves to Condensate water return reticulation valves along with High performance Electrical actuation solutions specifically developed for the Power Industry.

Valve & Actuator Range

Butterfly Valves

  • Size Range: DN40 - DN1200

    Pressure: PN10 - PN16

    Configuration: Rubber Lined (Replaceable) / PTFE

    Construction: Concentric / Double Eccentric

    Materials: Cast Iron / Ductile Iron / Carbon Steel / Stainless Steel

Gate Valves

  • Size Range: 1/4" - 48"

    Pressure: Class 150 - Class 2500

    Construction: Bolted Bonnet / Pressure Seal

    Materials: Cast Iron / Carbon Steel / Stainless Steel Alloys

Globe Valves

  • Size Range: 1/4" - 48"

    Pressure: Class 150 - Class 2500

    Construction: Bolted Bonnet / Pressure Seal

    Materials: Cast Iron / Carbon Steel / Stainless Steel Alloys

Check Valves

  • Size Range: 1/4" - 48"

    Pressure: Class 150 - Class 2500

    Construction: Bolted Bonnet / Pressure Seal

    Materials: Cast Iron / Carbon Steel / Stainless Steel Alloys

Ball Valves

  • Size Range: 1/4" - 24"

    Pressure: Class 150 - Class 2500

    Configuration: 2 Way / 3 Way / 4 Way / Top Entry

    Construction: Floating / Trunnion Mounted

    Materials: Carbon Steel/ Low Carbon Steel / Stainless Steel Alloys

High Pressure Steam Valves

  • Size Range: 2" - 24"

    Pressure: Class 150 - Class 600

    Configuration: Full Bore / Reduced Bore

    End Connections: Flanged / Buttweld

    Materials: Carbon Steel / Duplex / Super Duplex / Aluminium Bronze / Stainless Steel Alloys

Globe Control Valves

  • Size Range: 1/2" - 12" - Larger sizes available on request

    Pressure: PN16-PN40 / ANSI Class 150 Class 300

    Pneumatic Control Valves for Liquids, Gases and Steam

    Materials: Carbon Steel / Low Carbon Steel / Stainless Steel Alloys

Safety Valves

  • Size Range: 1/2" x 2" - 12" x 16"

    Pressure: Class 150 - Class 2500

    Design to ASME VIII / API STD 526 / ISO 4126

    Configuration: Conventional / Bellows Sealed

    Construction: Full Lift / Semi Lift

    Materials: Carbon Steel / Low Carbon Steel / Stainless Steel Alloys

Pneumatic Actuators

  • Rack & Pinion / Scotch Yoke Design

    Torque: 3 N.M - 700,000 N.M

    Configuration: Double Acting / Spring Return

    Construction: Hard Anodized Aluminium Body & Carbon+ ENP Pinion

    Coatings: Standard Anodized or C5M for harsh environments

Electric Actuators

  • Torque: 40 N.M - 3000 N.M

    Configuration: Quarter Turn / Multi Turn

    Construction: Hard Anodized Aluminium Body

    Power Supply: 1Ph / 3Ph

    Complete with Manual Override

Smart Valve Positioners

  • Smart & Analogue Type

    Linear / Rotary Valve Positioners

    HART / PROFIBUS / FIELDBUS Capable on order

    Construction: Standard / ATEX Rater Aluminium Housing

Automation Accessories

  • Mechanical & Proximity Switchboxes, Brackets & Couplings, Bespoke Pipework, Lock up Valves, Solenoid Valves and Air Filter Regulators.

The Coral Valves Commitment.

  • Empowering Power Generation.

    Coral Valves is a leading supplier of high-quality manually operated and automated isolation and control valves, along with high-performance electric actuators, tailored for the power generation market, notably coal-fired power stations. These critical facilities face multifaceted challenges, including extreme temperatures, variable pressures, and stringent emissions regulations. Our commitment to excellence shines through as we deliver top-tier products capable of withstanding these challenges. Our valves and actuators ensure precise control and reliability, enhancing operational efficiency and environmental compliance in the power generation sector.

  • Meeting the Demands of Coal-Fired Power Stations.

    Coal-fired power stations demand robust valve and actuation solutions, and Coral Valves rises to the occasion. We recognize the importance of maintaining optimal flow control, especially in the presence of abrasive coal particles and high temperatures. Our valves and electric actuators are engineered to excel in these conditions, providing dependable performance and longevity. Our commitment extends beyond products to comprehensive support, ensuring our clients have access to top-quality solutions that tackle the specific challenges encountered in coal-fired power generation.

  • Unwavering Quality, Enduring Support.

    Coral Valves' unwavering commitment to quality and support is our hallmark in the power generation sector, particularly coal-fired power stations. We understand that reliability is paramount in ensuring uninterrupted power production. Our valves and electric actuators embody precision engineering and cutting-edge technology, resulting in top-quality products designed to meet and exceed industry standards. Our clients can trust that we provide the highest-quality solutions, empowering them to navigate the challenges of coal-fired power generation with confidence and efficiency.
