Concentrated

Solar Power Valves

Coral Valves manufactures and distributes a wide range of gate, globe, check, safety, ball and butterfly valves for the Concentrated Solar Power industry. We cover all areas of the plant, from HTF to High Pressure Steam having supplied hundreds of valves for the solar field, HTF conductions and molten salts storage systems.

Valve & Actuator Range

Butterfly Valves

  • Size Range: DN40 - DN1200

    Pressure: PN10 - PN16 / ANSI Class 150 - Class 600

    Configuration: Concentric / Double Offset / Triple Offset

    Construction: Resilient Seated / Metal Seated

    Materials: Cast Iron / Ductile Iron / Carbon Steel / Stainless Steel Alloys

Gate Valves

  • Size Range: 1/4" - 48"

    Pressure: Class 150 - Class 2500

    Construction: Bolted Bonnet / Pressure Seal

    Materials: Cast Iron / Carbon Steel / Stainless Steel Alloys

Globe Valves

  • Size Range: 1/4" - 48"

    Pressure: Class 150 - Class 2500

    Construction: Bolted Bonnet / Pressure Seal

    Materials: Cast Iron / Carbon Steel / Stainless Steel Alloys

Check Valves

  • Size Range: 1/4" - 48"

    Pressure: Class 150 - Class 2500

    Construction: Bolted Bonnet / Pressure Seal

    Materials: Cast Iron / Carbon Steel / Stainless Steel Alloys

HTF Ball Valves

  • Size Range: 1/4" - 24"

    Pressure: Class 150 - Class 2500

    Configuration: 2 Way / 3 Way / 4 Way / Top Entry

    Construction: Floating / Trunnion Mounted

    Materials: Carbon Steel/ Low Carbon Steel / Stainless Steel Alloys

High Pressure Steam Valves

  • Size Range: 1/4" - 48"

    Pressure: Class 150 - Class 2500

    Construction: Bolted Bonnet / Pressure Seal / Parallel Slide

    Materials: Cast Iron / Carbon Steel / Stainless Steel Alloys

Globe Control Valves

  • Size Range: 1/2" - 12" - Larger sizes available on request

    Pressure: PN16-PN40 / ANSI Class 150 Class 300

    Pneumatic Control Valves for Liquids, Gases and Steam

    Materials: Carbon Steel / Low Carbon Steel / Stainless Steel Alloys

Safety Valves

  • Size Range: 1/2" x 2" - 12" x 16"

    Pressure: Class 150 - Class 2500

    Design to ASME VIII / API STD 526 / ISO 4126

    Configuration: Conventional / Bellows Sealed

    Construction: Full Lift / Semi Lift

    Materials: Carbon Steel / Low Carbon Steel / Stainless Steel Alloys

Pneumatic Actuators

  • Rack & Pinion / Scotch Yoke Design

    Torque: 3 N.M - 700,000 N.M

    Configuration: Double Acting / Spring Return

    Construction: Hard Anodized Aluminium Body & Carbon+ ENP Pinion

    Coatings: Standard Anodized or C5M for harsh environments

Electric Actuators

  • Torque: 40 N.M - 3000 N.M

    Configuration: Quarter Turn / Multi Turn

    Construction: Hard Anodized Aluminium Body

    Power Supply: 1Ph / 3Ph

    Complete with Manual Override

Smart Valve Positioners

  • Smart & Analogue Type

    Linear / Rotary Valve Positioners

    HART / PROFIBUS / FIELDBUS Capable on order

    Construction: Standard / ATEX Rater Aluminium Housing

Automation Accessories

  • Mechanical & Proximity Switchboxes, Brackets & Couplings, Bespoke Pipework, Lock up Valves, Solenoid Valves and Air Filter Regulators.

The Coral Valves Commitment.

  • Empowering Concentrated Solar Power.

    Coral Valves leads the way in supplying top-tier manually operated and automated isolation and control valves, alongside high-performance pneumatic and electric actuators, to the demanding concentrated solar power markets. These cutting-edge solar facilities confront a unique set of challenges, including extreme temperatures, precise energy control, and efficient thermal storage. Our products are meticulously designed to withstand these formidable challenges. Coral Valves provides solutions that not only ensure reliable energy production but also address the complexities of thermal storage, enhancing efficiency in concentrated solar power applications.

  • Navigating the Solar Energy Frontier.

    Concentrated solar power relies on precision and versatility to harness the sun's energy effectively. In addition to high temperatures, the industry faces challenges related to thermal cycling, thermal shock, and the need for enhanced control in energy storage systems. Coral Valves understands the critical importance of accurate flow control and adaptability in such conditions. Our valves and actuators are purpose-built to thrive in these environments, delivering not only dependable performance but also adaptability and longevity. Beyond products, our commitment extends to providing comprehensive support, ensuring our clients receive top-quality, innovative solutions tailored to the multifaceted challenges encountered in concentrated solar power.

  • Uncompromising Quality, Sustained Support.

    Coral Valves' unwavering commitment to quality and support sets new standards in the concentrated solar power sector. We recognize that reliability is paramount for continuous energy generation, especially given the industry's unique demands. Our valves and actuators embody precision engineering and state-of-the-art technology, resulting in top-quality products designed to not only meet but exceed industry standards. Our clients can trust that we provide the highest-quality solutions, empowering them to harness solar energy efficiently, adapt to thermal fluctuations, and confront the intricate challenges of thermal energy storage with confidence and resilience.
